| YEAR | MAKE - ENGINE SERIES |
|---|---|
| 1991 | Dodge - D250 - 5.9 |
| 1991 | Dodge - D350 - 5.9 |
| 1991 | Dodge - W250 - 5.9 |
| Manufacturer Part Number | 224-3525WR-STD |
| Manufacturer Name | Mahle |
| GTIN | 27067913623 |
| Shipping Weight | 4.00 lb. |
| Shipping Length | 14 in. |
| Shipping Width | 12 in. |
| Shipping Height | 10 in. |
| Prop 65 | WARNING: Cancer & Reproductive Harm - P65Warnings.ca.gov |
| Casting Number | 102L37 |
| Material | Aluminum |
| Maximum Oversize | .040" 1.00MM |
| Bore Diameter | 4.016" 102.00MM |
| Piston Skirt Clearance | 0.0047IN |
| Measure Skirt Clearance At | 0.472" from the bottom of skirt |
| Piston Pin Diameter | 1.575" 40.00MM |
| Pin Hole Location | Offset |
| Head Type Description | Reentrant Bowl |
| Recess Depth | 0.697IN |
| Recess Diameter | 2.328IN |
| Recess Volume | 43.2cc |
| Compression Height | Standard |
| Compression Distance | 2.817" 71.56MM |
| Compression Ring Groove 1 | 3.00MM |
| Compression Ring Groove 2 | 2.40MM |
| Oil Ring Groove Width 1 | 4.00MM |
| Truck Applications | Dodge 1st Generation 1988-93 |
|---|---|
| SKU | 224-3525WR-STD |
| Manufacturer | Mahle |
| Weight | 4.00 |
