| Transmission | BD ProTech68 pressure control module ramps up line pressure to 250 psi using MAP sensor to input load and adjust pressure required |
| Hard anodized valve body and new solenoid pack installed in every unit | Proforce 3D Torque Converter |
| Custom bonded gasket valve body separator plate increases line pressure while stopping internal cross leaks | Triple Disc |
| Heavy duty cam & roller design Low Reverse one way clutch | Enhanced Stall - Street/Towing applications |
| New 4C billet spring retainer | HD springs absorb shock of engagement |
| Steel girdle added to 2C piston to allow for more clutches and broader apply area | Stamp forged 1-piece cover |
| BD durable QT100 pressure plates allow for increased clutch counts and reduce deflection and distortion within the clutch drum | Eliminates warpage from clutch heat |
| Over Drive clutches 33% increase & 2C clutches 33% increase | Taller cover can be rebuilt more often |
| Custom Big Stack Overdrive shaft | Trapezoid teeth design |
| BD reinforced accumulator plate | Engineered tighter tolerances |
| TCC limit valve machined and sleeved to address high wear area with in pump | Self-centering trapezoid teeth design increases contact decreases wear and chatter |
| BD Deep sump oil pan adds extra fluid and cooling capacity while reducing case flex | Thrust bearings - not plastic thrust washers |
| YEAR | MAKE - ENGINE SERIES |
|---|---|
| 2007-2010 | Dodge - 6.7 Ram 2500 |
| 2007-2010 | Dodge - 6.7 Ram 3500 |
| 2011-2018 | Dodge (Ram) - 6.7 2500 |
| 2011-2018 | Dodge (Ram) - 6.7 3500 |
| Manufacturer's Part Number | 1064264SS |
| Manufacturer Name | BD Diesel Performance |
| Weight (Lbs) | 315 |
| Length | 23.5 |
| Width | 44.5 |
| Height | 27.3 |
| UPC | 990011407502 |
| Country of Origin | CA |
| HTC | 8708996890 |
| Hazmat | N |
| Prop 65 Cancer | Y |
| Prop 65 Reproductive | Y |
| Prop 65 Labeling | WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov |
| Install Time | 9 Hours |
| Parts Warranty | 36-Months, 150,000 Miles |
| Labour Warranty | 12-Months, 24,000 miles |
| Emissions | This product does not require an EO in California. By nature of its design, it is legal for sale and use in all 50 states. Replacement parts included. (EMS:4) |
| BD Core Acceptance | Click to View |
| 1030369 - Line Pressure Module | Click to View |
| 68rfe Transmission Instructions | Click to View |
BD Diesel is an innovative and world class company distributing products North American wide for domestic diesel and gas applications.
After final assembly, our 68rfe transmissions are paired with a matched BD torque converter, engineered for tighter tolerances and designed for enhanced street and towing applications. The torque converter and transmission are then dyno tested together to ensure the end product meets BD闁肩儤甯￠崺鈧柛鏂裤€ requirements for ultimate performance and reliability.
The relearn procedure resets the adaptive mode of the transmission and re-calibrates the shift time. Not following the relearn procedure properly, can lead to premature transmission wear or even catastrophic transmission damage.
| Truck Applications | Dodge 6.7 2007-09, Dodge 6.7L 2010-12, Dodge 6.7L 2013-2018 |
|---|---|
| SKU | 1064264SS |
| Manufacturer | BD Diesel Performance |
| Weight | 315.00 |
